1 # UART Bootloader for STM32F4 MCU 2 3 This is a simple UART bootloader written for STM32f4 MCUs based on the libopencm3 library. 4 5 ## Building 6 7 clone this repo, build and setup the submodules and run make. 8 ``` 9 git clone git@github.com:mdnr/stm32f4-uart-bootloader.git --recurse-submodules --shallow-submodules 10 cd stm32f4-uart-bootloader 11 make -C src/shared/opencm3/ TARGETS=stm32/f4 12 cp configs/FreeRTOSConfig.h src/app/freertos/include/ 13 make 14 ``` 15 The versioning of the build output is done automatically based on the latest tag and commit hash. 16 (tag format must be `v<MAJOR>.<MINOR>`, e.g. `v0.1`) 17 18 ## Memory layout 19 20 Currently the flash memory of the MCU is divided as below: 21 22 ``` 23 **************************************** 24 0x0800000: Flash base / Bootloader start 25 Bootloader: 16KB 26 **************************************** 27 0x0804000: Bootloader end / Parameters start 28 Parameters: 8KB (Config and application settings based on user's needs) 29 ---------------------------------------- 30 0x8002000: Parameters end / Diagnostic area start 31 Doggy litter box: 8KB (Watchdog register dump area) 32 **************************************** 33 0x0808000: Application start 34 Aplication Vector table 35 ---------------------------------------- 36 Firmware info (Version, size, etc) 37 ---------------------------------------- 38 Application code 39 **************************************** 40 ``` 41 The root directory Makefile takes care of compiling both binaries 42 for bootloader and application and flashing them in the corresponding addresses. 43 44 - `make all`: compile both application and bootloader binaries 45 - `make app`: compile application binary 46 - `make bl`: compile bootloader binary 47 - `make flash`: flash both application and bootloader to MCU 48 - `make flash-bl`: flash bootloader only without touching the application 49 - `make flash-app`: flash application only without touching the bootloader 50 51 Also there are 2 debug targets `(make fw-debug and make bl-debug)` for debugging the bootlaoder and application 52 remotely on the target. 53 54 ## Using the bootloader 55 56 Run the python script from the root directory to connect to the serial port using a usb-serial converter 57 ``` 58 ./bootloader.py 59 ``` 60 Specify the port connected to the MCU board (e.g. `/dev/ttyUSB0`) and choose one of 61 the actions listed: 62 1. `Read parameters`: Read current parameters stored in the MCU's parameter section 63 2. `Update parameters`: Write new parameters to the flash without touching application code 64 3. `Read firmware info`: Read firmware verison, size, etc. 65 4. `Reset the core`: Send reboot command ans start bootloader process. 66 5. `Lock serial line`: Lock the UART line in case it's used by the application 67 6. `UnLock serial line`: Release the UART lock 68 7. `Read diagnostics`: Read the dumped diagnostic data from corresponding section 69 8. `Abort`: Quit the bootlaoder 70 71 ## TODO 72 73 - Adding GSM layer to support OTA update 74 - Rewriting `bootloader.py` in C perhaps and adding proper UI to it 75 - Adding Encryption
